Bơm chìm Tsurumi Seri U kiểu cánh Vortex
Size (mm ) : 40-80
Công suất (Kw) : 0.25 – 3.7
Model Selection
| Discharge Bore (mm) |
Model | Motor Output (kW) |
Phase | Starting Method |
Solids Passage (mm) |
|---|---|---|---|---|---|
| 40 | 40U2.25S | 0.25 | Single | Split-phase | 35 |
| 40 | 40U2.25 | 0.25 | Three | D.O.L. | 35 |
| 50 | 50U2.4S | 0.4 | Single | Capacitor Start | 35 |
| 50 | 50U2.4 | 0.4 | Three | D.O.L. | 35 |
| 50 | 50U2.75 | 0.75 | Three | D.O.L. | 35 |
| 50 | 50U21.5 | 1.5 | Three | D.O.L. | 35 |
| 80 | 80U2.75 | 0.75 | Three | D.O.L. | 46 |
| 80 | 80U21.5 | 1.5 | Three | D.O.L. | 46 |
| 80 | 80U22.2 | 2.2 | Three | D.O.L. | 56 |
| 80 | 80U23.7 | 3.7 | Three | D.O.L. | 56 |
Automatic, Auto‐Alternation, or Guide Rail Fitting model available. Refer to the individual catalog.
