| PUMP TECHNICAL DATA
• Maximum working pressure: 10 bar • Maximum temperature of the liquid: -10°C ÷ +90°C -10°C ÷ +110°C (L-H-HS-HW-HSW-E versions) -10°C ÷ +120°C (ES version) • MEI >0,4 for 3(L) SERIES 2 poles, MEI >0,1 for 3(L) SERIES 4 poles MOTOR TECHNICAL DATA • High efficiency IE2 motors starting from 0,75kW • Self-ventilated 2 and 4 poles asynchronous motor • Class of insulation F (B for high temperatures) • IP 55 protection degree • 230V ±10% single phase voltage, 50Hz, • 220-240/380-415V ±5% (up to 0,55kW included) three phase voltage, 50Hz for 3(L)M4 SERIES, • 230/400V ±10% (from 0,75kW to 4kW included) three phase voltage, 50Hz for 3(L)M4 SERIES, • 230/400V ±10% (up to 4kW included) three phase voltage, 50Hz for the rest of the range • 400/690V ±10% (from 5,5 kW and above) three phase voltage, 50Hz
|
MATERIALS
• Pump casing and casing cover in: – AISI 304 for 3 SERIES 32-125/160/200 40-125/160/200 50-125/160 65-125/160/200 – AISI 316L for 3L SERIES 32-125/160/200 40-125/160/200 50-125/160 65-125/160/200 – AISI 316 microcasted for 3L SERIES 65-250 80-160/200/250 • Impeller in: – AISI 316 microcasted for 3 SERIES 65-125/160/200 3L SERIES 65-125/160/200 65-250 80-160/200/250 |
PERFORMANCE RANGE 3 SERIES at 2900 min‾¹ (according to ISO 9906 Attachment A)
PERFORMANCE TABLE 32-40-50
| Model | P2 | Q=Flow rate | ||||||||||||||
| l/min 100 | 150 | 200 | 300 | 333 | 360 | 400 | 450 | 500 | 600 | 700 | 800 | 1000 | 1200 | |||
| [HP] | [kW] | m3/h 6 | 9 | 12 | 18 | 20 | 22 | 24 | 27 | 30 | 36 | 42 | 48 | 60 | 72 | |
| H=Head [m] | ||||||||||||||||
| 3 SERIES(.) 32-125/1.1(M) | 1,5 | 1,1 | 21 | 19,9 | 18,4 | 14,1 | 12 | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 32-160/1.5(M) | 2 | 1,5 | 28 | 26,5 | 24,5 | 19,2 | 17 | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 32-160/2.2(M) | 3 | 2,2 | 35,5 | 34 | 32 | 27 | 25 | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 32-200/3.0 | 4 | 3 | 42 | 40 | 37,5 | 31 | 28 | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 32-200/4.0 | 5,5 | 4 | 53,5 | 52 | 49,5 | 43,5 | 40,5 | 38 | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 32-200/5.5 | 7,5 | 5,5 | 69 | 67,5 | 65 | 58,5 | – | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 32-200/7.5 | 10 | 7,5 | 69 | 67,5 | 65 | 58,5 | 55,5 | 53 | 49 | 44 | – | – | – | – | – | – |
| 3 SERIES(.) 40-125/1.5(M) | 2 | 1,5 | – | – | 19 | 17,6 | 17 | 16,5 | 15,7 | 14,5 | 13,2 | 10,3 | 7 | – | – | – |
| 3 SERIES(.) 40-125/2.2(M) | 3 | 2,2 | – | – | 25,5 | 24 | 23,5 | 23 | 22 | 21 | 19,5 | 16,4 | 13 | – | – | – |
| 3 SERIES(.) 40-160/3.0 | 4 | 3 | – | – | 29,5 | 27,5 | 27 | 26,5 | 25,5 | 24 | 22,5 | 20 | 17 | – | – | – |
| 3 SERIES(.) 40-160/4.0 | 5,5 | 4 | – | – | 38,5 | 37 | 36 | 35,5 | 34,5 | 33 | 32 | 29 | 25,5 | – | – | – |
| 3 SERIES(.) 40-200/5.5 | 7,5 | 5,5 | – | – | 45,5 | 44 | 43 | 42,5 | 41 | 39,5 | 38 | 35 | 31 | – | – | – |
| 3 SERIES(.) 40-200/7.5 | 10 | 7,5 | – | – | 57 | 55,5 | 55 | 54,5 | 53,5 | 52,5 | 51 | 47,5 | 44 | – | – | – |
| 3 SERIES(.) 40-200/11 | 15 | 11 | – | – | 71 | 70 | 70 | 69,5 | 68,5 | 67,5 | 66 | 63 | 59 | – | – | – |
| 3 SERIES(.) 50-125/2.2(M) | 3 | 2,2 | – | – | – | – | – | – | 17,5 | 17 | 16,3 | 14,9 | 13,4 | 11,7 | 8 | – |
| 3 SERIES(.) 50-125/3.0 | 4 | 3 | – | – | – | – | – | – | 20,5 | 20 | 19,6 | 18,4 | 17 | 15,4 | 11,8 | 8 |
| 3 SERIES(.) 50-125/4.0 | 5,5 | 4 | – | – | – | – | – | – | 26 | 25,5 | 25 | 24 | 22,5 | 21,5 | 17,9 | 14 |
| 3 SERIES(.) 50-160/5.5 | 7,5 | 5,5 | – | – | – | – | – | – | 31 | 30,5 | 30 | 28,5 | 27 | 25,5 | 22 | 18 |
| 3 SERIES(.) 50-160/7.5 | 10 | 7,5 | – | – | – | – | – | – | 38,5 | 38 | 37,5 | 36 | 35 | 33,5 | 30 | 26 |
| 3 SERIES(.) 50-200/9.2 | 12,5 | 9,2 | – | – | – | – | – | – | – | – | 50 | 49 | 47,5 | 45,5 | 40,5 | 34 |
| 3 SERIES(.) 50-200/11 | 15 | 11 | – | – | – | – | – | – | – | – | 56 | 55 | 54 | 52 | 48 | 42 |
| 3 SERIES(.) 50-200/15 | 20 | 15 | – | – | – | – | – | – | – | – | 70 | 69 | 68 | 66 | 62 | 57 |
(M) Single phase version only for 3M SERIES
PERFORMANCE TABLE 65-80
| Model | P2 | Q=Flow rate | |||||||||||||||||
| l/min 600 | 700 | 900 | 1300 | 1500 | 1700 | 1900 | 2100 | 2200 | 2300 | 2400 | 2500 | 3000 | 3400 | 3600 | 3800 | 4000 | |||
| [HP] | [kW] | m3/h 36 | 42 | 54 | 78 | 90 | 102 | 114 | 126 | 132 | 138 | 144 | 150 | 180 | 204 | 216 | 228 | 240 | |
| H=Head [m] | |||||||||||||||||||
| 3 SERIES(.) 65-125/4.0 | 5,5 | 4 | 19,8 | 19 | 17,3 | 13,3 | 11 | 8,6 | 6,3 | – | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-125/5.5 | 7,5 | 5,5 | – | 24 | 22,2 | 18 | 15,7 | 13,3 | 10,8 | 8 | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-125/7.5 | 10 | 7,5 | – | 29,5 | 27,8 | 23,5 | 21,1 | 18,7 | 16,1 | 13,4 | 12 | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-160/7.5 | 10 | 7,5 | – | 30 | 28,6 | 24,8 | 22,5 | 19,9 | 17,1 | 14,2 | – | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-160/9.2 | 12,5 | 9,2 | – | 34,5 | 32,8 | 28,8 | 26,5 | 23,9 | 21,1 | 18,3 | 16,8 | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-160/11 | 15 | 11 | – | 38,5 | 37,1 | 33,1 | 30,9 | 28,4 | 25,8 | 23 | 21,5 | 20 | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-160/15 | 20 | 15 | – | 45,5 | 44 | 40 | 37,8 | 35,3 | 32,6 | 29,6 | 28 | 26,5 | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-200/15 | 20 | 15 | – | 51 | 49 | 44 | 41,5 | 38,4 | 35,3 | 31,8 | 30 | – | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-200/18.5 | 25 | 18,5 | – | 58,5 | 56,5 | 51,5 | 49 | 46 | 43 | 39,7 | 38 | 36,3 | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-200/22 | 30 | 22 | – | 65,5 | 64 | 59,5 | 57 | 54 | 51 | 48 | 46,5 | 45 | – | – | – | – | – | – | – |
| 3 SERIES(.) 65-250/30 | 40 | 30 | – | – | 77 | 73,5 | 71 | 68 | 64,5 | 60 | 57,5 | 55 | 52 | – | – | – | – | – | – |
| 3 SERIES(.) 65-250/37 | 50 | 37 | – | – | 88 | 85,5 | 83 | 80,5 | 77,5 | 74 | 72 | 70 | 67,5 | 65 | – | – | – | – | – |
| 3 SERIES(.) 80-160/11 | 15 | 11 | – | – | – | 27,3 | 26,4 | 25,4 | 24,2 | 23 | 22,4 | 21,8 | 21,1 | 20,4 | 16,4 | 12,5 | – | – | – |
| 3 SERIES(.) 80-160/13 | 17,5 | 13 | – | – | – | 30,5 | 29,7 | 28,8 | 27,7 | 26,5 | 25,9 | 25,3 | 24,6 | 24 | 20,1 | 16,5 | 14,5 | – | – |
| 3 SERIES(.) 80-160/15R | 20 | 15 | – | – | – | 30,5 | 29,7 | 28,8 | 27,7 | 26,5 | 25,9 | 25,3 | 24,6 | 24 | 20,1 | 16,5 | 14,5 | – | – |
| 3 SERIES(.) 80-160/15 | 20 | 15 | – | – | – | 34 | 33,3 | 32,5 | 31,5 | 30,5 | 30 | 29,4 | 28,8 | 28,1 | 24,4 | 21 | 19,1 | 17 | – |
| 3 SERIES(.) 80-160/18.5 | 25 | 18,5 | – | – | – | 39 | 38,4 | 37,6 | 36,7 | 35,7 | 35,2 | 34,7 | 34,1 | 33,5 | 30 | 26,4 | 24,4 | 22,3 | 20 |
| 3 SERIES(.) 80-200/22 | 30 | 22 | – | – | – | 48 | 47 | 45,5 | 44,5 | 43 | 42 | 41 | 40 | 39 | 33,2 | 27,8 | 25 | – | – |
| 3 SERIES(.) 80-200/30 | 40 | 30 | – | – | – | 58,5 | 58 | 57 | 56 | 54,5 | 54 | 53 | 52 | 51 | 46,5 | 41,5 | 39 | 36,1 | 33 |
| 3 SERIES(.) 80-200/37 | 50 | 37 | – | – | – | 64 | 63 | 62 | 61 | 59,5 | 59 | 58 | 57,5 | 56,5 | 51,5 | 47 | 44,5 | 41,5 | 38,5 |
| 3 SERIES(.) 80-250/37 | 50 | 37 | – | – | – | 71,5 | 70,5 | 68,5 | 66,5 | 64 | 63 | 61,5 | 60 | 58,5 | 48,5 | 38 | – | – | – |
| 3 SERIES(.) 80-250/45 | 60 | 45 | – | – | – | 82,5 | 81,5 | 80 | 78 | 76 | 75 | 73,5 | 72,5 | 71 | 62 | 53 | 48 | 42,5 | – |
| 3 SERIES(.) 80-250/55 | 75 | 55 | – | – | – | 93,5 | 92,5 | 91,5 | 90 | 88,5 | 87,5 | 86,5 | 85,5 | 84 | 76,5 | 68,5 | 64,5 | 60 | 55 |
